DPANEL
Fine Pitch LED Display
■ Ultra light
■ Ultra thin
■ High protection
Optional GST(Glue Surface Treatment) Technology
■ Anti-crash ■ Water-proof
■ Anti-static ■ Moisture-proof
■ Anti-oxidant ■ Dust-proof
■ High contrast ■ No moire effect
■ High stability ■ Wide view angle
■ High accuracy ■ Long life time
Ultra Linght
Ultra Thin
Cable free connection
Quick set up and dismantle
Front installation
Front maintenace
Low brightness
High grey scale
Power backup
Signal backup
Fine Pitch LED Display
Adopt international golden ratio 16:9
Perfect splicing combination
Create multi-application suitable for global market
Technical parameters
| Item | P0.9 | P1.2 | P1.5 | P1.8 | P2.3 |
| Pixel pitch(mm) | 0.9375 | 1.25 | 1.56 | 1.875 | 2.34 |
| Pixel density(pixels/sqm) | 1137777 | 640000 | 409600 | 284444 | 182044 |
| Brightness(nits) | 500 | 600 | 600 | 600 | 600 |
| Scanning mode | Constant current drive | ||||
| Working environment | Indoor | Indoor | Indoor | Indoor | Indoor |
| Operating temperature | -30°C~60°C | -30°C~60°C | -30°C~60°C | -30°C~60°C | -30°C~60°C |
| Viewing angle | H/V:160° | H/V:160° | H/V:160° | H/V:160° | H/V:160° |
| Module size(mm) | 150 x 168.75 | 150 x 168.75 | 150 x 168.75 | 150 x 168.75 | 150 x 168.75 |
| Cabinet resolution(pixels) | 640 x 360 | 480 x 270 | 384 x 216 | 320 x 180 | 256 x 144 |
| Cabinet size(mm) | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 | 600 x 337.5 |
| Cabinet Thickness(mm) | 38 | 38 | 38 | 38 | 38 |
| Waterproof level | IP34 | IP34 | IP34 | IP34 | IP34 |
| Average power:(w/sqm) | 180 | 225 | 225 | 225 | 225 |
| Refresh rate:Hz | ≤3840 | ≤3840 | ≤3840 | ≤3840 | ≤3840 |
| Net weight: kgs | 5 | 5 | 5 | 5 | 5 |
